Vivotek SD8311E - AM-231 Corner Parapet Mount Diagrams

EN-2
Package Contents
1
5
1
0
0
0
0
2
0
2
G
Software CD
Warranty Card
Wall Mount BracketSD8311E/21E/12E/22E/13E/23E
GND
DO2-
DO1-
DO+
GND
D13
D12
D11
RJ45 Female/Female Coupler
Black & Clear Dome Covers
O-ring and Screws /
Alignment Sticker
Moisture Absorber /
Metal Ring
Silica gel
Silica gel
Quick Installation Guide
