Overview
The SD9365/9366-EHL is the latest professional speed dome camera from VIVOTEK,
specically designed to enhance low light surveillance in large coverage areas. Equipped with
250 M IR illuminators and a 20x or 30x optical zoom lens, the SD9365/9366-EHL provides a
superb low light image in the most challenging situations. The SD9365/9366-EHL also adopts
VIVOTEK's latest IR technology, VAIR (Vari-Angle IR). VIVOTEK's VAIR provides smooth vari-
angle adjustment of the IR illuminators, allowing broad coverage FOV and highly uniform IR
intensity while avoiding hot-spots that are traditionally associated with IR illumination.
The SD9365/9366-EHL is the rst PTZ surveillance camera with IR Illumination to utilize H.265
compression technology. When combined with VIVOTEK's Smart Stream II technology, users
can obtain bandwidth savings of up to 80% compared to traditional H.264. By combining
1080p full HD resolution with H.265, IR illuminators, VAIR, WDR, and 30x optical zoom, the
SD9365/9366-EHL is able to capture ne details at top-notch quality, 24 hours a day, 7 days a
week. The camera comes with an IP66- and NEMA 4X-rated housing that protects against rain,
dust, and corrosion. The SD9365/9366-EHL features a wide operating temperature range from
-40°C to 55°C, ensuring continuous operation under the most extreme weather conditions and
hazardous environments. This makes the SD9365/9366-EHL ideally suited to monitor wide open
spaces such as ports, highways, cities, and parking lots where high-level precision is required.
As with all VIVOTEK true day/night cameras, the SD9365/9366-EHL features a removable IR-
cut lter, maintaining clear images 24 hours a day. Audio detection is included by recognizing
changes in ambient noise. The SD9365/9366-EHL also includes a SD/SDHC/SDXC card slot
and supports up to 60 fps in 1080P full HD.
Revision History
■ Rev. 1.0: Initial release
■ Rev. 1.1: Added the description for the Focus window function.
■ Rev. 1.2: Corrected the DI/DO pin related description, and updated the I/O combo cable drawing.
■ Rev. 1.3: Added SD9366-EH-v2.
■ Rev. 1.4: Updated password policy, SD card capacity, video profiles, use of RTSP players,
authentication, system time time zone, logs, RTSP streaming, and URL command update.
NOTE:
If powered by a power adapter, the adapter should be properly grounded.
