294
ERROR: The device does not exist or is busy
ERROR: Formatted successfully, but cannot create database
8.39 Methods for Accessing Streaming
8.39.1 Get Stream URI (capability_media_streamprofiles_support = 1)
Note: This request requires Viewer access privileges.
Syntax:
For RTSP, the user needs to input the URL below into a RTSP compatible player.
rtsp://<servername>:<port>/media2/stream.sdp?profile=<streamprofile_i<0~(n-1)>_token>[&<par
ameter>=<value>]
 “n” is the maximum stream profile number (capability_media_streamprofiles_num)
 “streamprofile_i<x>_token” is the unique identifier for each profile, x is within
0~(capability_media_streamprofiles_num)-1.
 port is the rtsp port.
Please refer to the streamprofile group for requesting the stream profile token value for each
profile.
PARAMETER VALUE DESCRIPTION
pimssm 1 1: Enable the feature of Protocol
Independent Multicast - Source
Specific Multicast.
* This field is only required when
using PIM-SSM feature.
* Only valid when
network_rtsp_pimssm_enable=1.
Example:
Request the streaming of streamprofile_i0_token=profile200,
rtsp://192.168.1.1:554/media2/stream.sdp?profile=profile200
Note:
If the requested certain profile streamprofile_i<x>_occupied=0, which indicates stream profile <x>
has not been created, the above method for requesting RTSP streaming will fail.
8.39.2 Get SDP for always multicast
(capability_media_streamprofiles_support = 1)
