EN - 2
Physical Description
2
083236
S
Outer View
Built-in Microphone
Dome cover
IMPORTANT:
Record the MAC address under the camera base
before installing the camera.
Inner View
Header (J7)
Spring Contacts (A)
Lens
Contacts for Internal Microphone (B)
Header (J6)
Ethernet 10/100 RJ45 Socket
MicroSD/SDHC/SDXC Card Slot
Reset Button
Status LEDs
Cabling Cutout
