EN - 3
English
Hardware Installation
3
Release button
First, open the dome cover by pressing the release button. You may squeeze the opposite edge of
the dome cover if the dome cover does not come off easily. Then, follow the steps below to install the
camera to either a ceiling or a wall.
If you plan to route cables from the side of camera,
remove the rubber slide cover from the dome cover.
Slide cover
Connect the supplied power & IO cables if your switch
does not support PoE. Connect the white header
connectors to J6 and J7 on the camera.
Connecting Ethernet Cable
& the Power and IO Cable
J6
J7
Power & IO Cable
To Next Page
