Components - Connect a component or composite devices.
USB - Connect a USB thumb drive to play photo, music, or video.
HDMI - Connect an HDMI device.
HDMI - Connect an HDMI device.
RCA Audio Out- Connect an RCA audio device, such as sound bar.
Optical Audio Out - Connect an optical/SPDIF audio device, such as home audio receiver.
Power - Press to turn on the TV. Press and hold to turn the TV o.
Input - Press to access the input menu.
Note: The image shown here is for illustrative purposes only and may be subject to change.
The actual number of ports and their locations may vary, depending on the model.
Volume - Press to increase or decrease the TV volume level.
Ethernet - Connect an Ethernet cable to modem/ router.*
Coaxial - Connect a coaxial cable from cable, satellite, or antenna.
REAR PANEL
EX
AMPLE OTHER SELECT MODELS
*Port not available on D39f-F0 & D48f-F0
