5
26
Creating a Custom Picture Mode
Custom picture modes allow you to save a group of custom
settings for various viewing conditions and video sources.
Custom picture modes can be created manually.
A new custom picture mode is created automatically
whenever picture settings are changed while in any
preset picture mode.
A custom picture mode only applies to the input
(HDMI-1, COMP, etc.) in use when it was created. Each
input can have up to eight custom picture modes.
To create a custom picture mode manually:
1. From the PROFESSIONAL
PICTURE menu, use the Arrow
buttons to highlight Create
Picture Mode, and then press
OK. The CREATE PICTURE MODE
menu is displayed.
2. Use the Arrow buttons to enter
a name for your custom picture
mode using the on-screen
keyboard.
3. Highlight Done and press OK.
4. Make any desired changes to
the picture settings.
5. Press the EXIT button to exit the
menu screens.
VIZIO
CREATE PICTURE MODE
Custom1_
Done
a b c d e f g h i
j k l m n o p q r
s t u v w x y z 0
1 2 3 4 5 6 7 8 9
.@# .com Space
To show or hide the Ramp Test Pattern:
1. From the Color Tuner menu, use the Arrow buttons to
highlight Color Tuner, and then press the Left/Right Arrow
buttons until the Ramp Test Pattern menu is displayed.
2. Use the Arrow buttons on the remote to highlight Off. Use
the Left/Right Arrow buttons to select the color for the ramp
test pattern. Selecting a color immediately shows that color
ramp.
—or—
To hide the Ramp Test Pattern, use the Left/Right Arrow
buttons to highlight Off.
3. When you are finished, press the EXIT button.
Ramp Test Pattern
Off

Table of Contents

Other manuals for Vizio E500i-A1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Vizio E500i-A1 and is the answer not in the manual?

Vizio E500i-A1 Specifications

General IconGeneral
Response time8 ms
Display diagonal50 \
LED backlighting type-
Supported video modes1080p
Contrast ratio (dynamic)2000000:1
Viewing angle, horizontal176 °
Supported graphics resolutions1920 x 1080 (HD 1080)
RMS rated power8 W
Built-in subwooferNo
Number of speakers2
HDMI ports quantity4
DVI-D ports quantity0
USB 2.0 ports quantity1
Wi-Fi standardsWi-Fi 4 (802.11n)
Product colorBlack
Panel mounting interface400 x 400 mm
Power consumption (standby)1 W
Power consumption (typical)77.8 W
Sustainability certificatesENERGY STAR
Package depth181.1 mm
Package width1260 mm
Package height760.98 mm
Package weight26980 g
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)263.14 mm
Height (with stand)713.23 mm
Weight (with stand)19480 g
Depth (without stand)81.03 mm
Width (without stand)1132 mm
Height (without stand)667 mm
Weight (without stand)16570 g
