Vizio E60-C3 Service Manual

18
Panoramic
Wide
Zoom
TV Name VIZIOTV
CEC
CEC
Disable
ARC only
Enable
Device Discovery
Power
Indicator
Off
On
Reset &
Admin
Reset TV to
Factory Defaults
VIZIO Privacy
Policy
Smart Interactivity
Off
On
Store Demo
Off
On
Guided
Setup
Channel
Setup
Network
Setup
User
Manual
2. Display adjustment
Only adjust HDMI Mode and copy to all of input source
General set-up:
Equipment Requirements:
Minolta CA-210 or Equivalent Color analyzer or equivalent instrument.
HDMI signal generator(ex:ASTRO VG871)
Input Signal Type:
1. white pattern(720P).
2. Select Picture mode to Standard mode and check the x, y data.
Input Injection Point:
HDMI cable

Vizio E60-C3 Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	60 \
Display brightness	- cd/m²
Native aspect ratio	16:9
LED backlighting type	Full-Array
Supported video modes	1080p
Contrast ratio (dynamic)	5000000:1
Viewing angle, horizontal	176 °
Display refresh rates supported	120 Hz
Motion interpolation technology	-
Music apps	Pandora, Spotify
Video apps	Netflix, YouTube
Lifestyle apps	Facebook, Twitter
Audio decoders	DTS Studio Sound
RMS rated power	10 W
Number of speakers	2
PC in (D-Sub)	No
HDMI ports quantity	3
DVI-D ports quantity	0
USB 2.0 ports quantity	1
Wi-Fi standards	Wi-Fi 4 (802.11n)
On Screen Display (OSD) languages	ENG, ESP, FRE
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.5 W
Package depth	172 mm
Package width	1447 mm
Package height	902 mm
Package weight	25400 g
Sustainability certificates	ENERGY STAR
Certification	UL, cUL, FCC Class B, BET7/ICES-003 Class B, IC, HDMI (CEC, ARC), Dolby Digital

Weight and Dimensions

Stand width	1186 mm
Depth (with stand)	279.9 mm
Height (with stand)	851.4 mm
Weight (with stand)	21000 g
Depth (without stand)	64.26 mm
Width (without stand)	1353 mm
Height (without stand)	786.4 mm
Weight (without stand)	20600 g
