62
CHAPTER 9.PARTS GUIDE
[1] SPARE PARTS LIST
E60-C3
Recommended Spare Parts List
Assembly Number/ Finish goods 75120C800-600-G
Region North America
Description E60-C3 ATSC LCD TV
Updated date 2014/12/23
Item Catalog Component NO. Object Description Usage Photo
1 Panel 76040YP00-600-G
LCD
Module,TFT,TV,60In
ch,1920x1080,350cd
/m**2,4500:1,6ms,G,
S600DH3-1
1
2
PCBA
01-60CAP081-01
E60-C3/CAP08,Moth
er Board
1
3 09-60CAP080-01
E60-C3/CAP08,Pow
er Board
1
4 03-60CAP080-01
E60-C3/CAP08,Key
pad board
1
