61
[4]IR+LED+ALS SCHEMATIC DIAGRAM
E60-C3
Write Add.: 0x20
Read Add. : 0x21
SCR1
H4D3.2-1PIN
1
WHI
ORG
D100
LED_White/Orange
19-223/S2T1D-C30/2T
1
23
4
C103
10U_10V_M
c0805_mor
12
Add C103 for IR reciver distance
in 2013/09/04
U100
IRM-H638M3/TR2
VOUT
3
GND
1
VCC
4
GND
2
C102
2.2U_6.3V_M
R101
22_F
12
ALS_CLK
ALS_SDA
+3V3_STB
LED-STB
IR_IN
LED_PWRON
+3V3_STB
C101
2.2U_6.3V_M
VR103
AVR-M1005C080MTACB_VR
1 2
VR104
AVR-M1005C080MTACB_VR
1 2
CN100
8P 1.0MM R/A
1
2
3
4
5
6
7
8
10 9
M2
NC_MARK2
1
IR_IN
+3V3_STB
ALS_SDA
ALS_CLK
VR100
AVR-M1005C080MTACB_VR
1 2
U101
JSA-1126
IC--SSO6-JSA1126
SDAT
6
SCLK
4
VDD
1
GND
3
ADDR
2
INT
5
VR101
AVR-M1005C080MTACB_VR
1 2
VR102
AVR-M1005C080MTACB_VR
1 2
