Vizio E60-C3 Service Manual

27
MAIN UNIT:
YES
YES
YES
No sound from external input devices (2)
Does not the sound of the audio signal from (USB input) go out?
YES
NO
Is USB stick audio format correct? Change to correct audio format.
Is +5V input to pin( 2,3) of IC U6500?
Is USB +5V from U6500 pin (6~8) to the pin 1 of
CN6500?
Refer to “No sound output in all modes”.
NO
NO
Check the power supply.
Check the peripheral circuit of IC U6500.
YES
YES
Is the USB con (CN6500) signal properly sent to
pin (U24) (USB_DP_P0) and pin (U25)
(USB_DM_P0 ) or pin (T24) (USB_DP_P1) and pin
(T25) (USB_DM_P1 )of IC U107?
NO
Check the circuit between CN6500 and U107.

Vizio E60-C3 Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	60 \
Display brightness	- cd/m²
Native aspect ratio	16:9
LED backlighting type	Full-Array
Supported video modes	1080p
Contrast ratio (dynamic)	5000000:1
Viewing angle, horizontal	176 °
Display refresh rates supported	120 Hz
Motion interpolation technology	-
Music apps	Pandora, Spotify
Video apps	Netflix, YouTube
Lifestyle apps	Facebook, Twitter
Audio decoders	DTS Studio Sound
RMS rated power	10 W
Number of speakers	2
PC in (D-Sub)	No
HDMI ports quantity	3
DVI-D ports quantity	0
USB 2.0 ports quantity	1
Wi-Fi standards	Wi-Fi 4 (802.11n)
On Screen Display (OSD) languages	ENG, ESP, FRE
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.5 W
Package depth	172 mm
Package width	1447 mm
Package height	902 mm
Package weight	25400 g
Sustainability certificates	ENERGY STAR
Certification	UL, cUL, FCC Class B, BET7/ICES-003 Class B, IC, HDMI (CEC, ARC), Dolby Digital

Weight and Dimensions

Stand width	1186 mm
Depth (with stand)	279.9 mm
Height (with stand)	851.4 mm
Weight (with stand)	21000 g
Depth (without stand)	64.26 mm
Width (without stand)	1353 mm
Height (without stand)	786.4 mm
Weight (without stand)	20600 g
