Vizio E70-E3 User Manual

3
Note: The images shown here are for illustrative purposes only and may be subject to change. The actual on-screen image and text may vary, depending on the model.
To show or hide the Flat Test Pattern:
1. From the Color Tuner menu, use the Arrow buttons to highlight
Color Tuner, and then press the Left/Right Arrow buttons until
the Flat Test Pattern menu is displayed.
Flat Test Pattern
Off
2. Use the Arrow buttons on the remote to highlight O. Use the
Left/Right Arrow buttons to select the percentage brightness for
the at test pattern. Selecting a percentage immediately shows
the at pattern at that brightness.
—or—
To disable the Flat Test Pattern, use the Left/Right Arrow
buttons to highlight O.
3. When you are nished, press the EXIT button.
To show or hide the Ramp Test Pattern:
1. From the Color Tuner menu, use the Arrow buttons to highlight
Color Tuner, and then press the Left/Right Arrow buttons
until the Ramp Test Pattern menu is displayed.
2. Use the Arrow buttons on the remote to highlight O. Use the
Left/Right Arrow buttons to select the color for the ramp test
pattern. Selecting a color immediately shows that color ramp.
—or—
To hide the Ramp Test Pattern, use the Left/Right Arrow
buttons to highlight O.
3. When you are nished, press the EXIT button.
Ramp Test Pattern
Off
To show or hide the SMPTE Test Pattern:
1. From the Color Tuner menu, use the Arrow buttons to highlight
Color Tuner, and then press the Left/Right Arrow buttons until
the SMPTE Test Pattern menu is displayed.
SMPTE Test Pattern
Off
2. Use the Arrow buttons on the remote to highlight O. Use the
Left/Right Arrow buttons to highlight On to show the SMPTE
Pattern.
—or—
To hide the SMPTE Test Pattern, use the Left/Right Arrow
buttons to highlight O.
3. When you are nished, press the EXIT button.
18

Vizio E70-E3 Specifications

General

Screen Type	led
Wall Mount	400mm x 400mm
Features	xled, xtreme black engine w/ 12 local dimming zones, vizio smartcast, compatible with google assistant and amazon alexa
Tuner	not included
Screen Size	69.5 inches, 70 inches
Refresh Rate	120hz
Closed Captioning	yes
HDR	yes
Built-In Speakers	yes
Surround Sound	dts studio sound, dts trusurround, dts truvolume, dolby digital plus
Speakers Output	20 watts
HDMI ARC Ports	yes
USB Ports	1
USB 2.0 Ports	0
Ethernet	yes
RF Antenna	yes
Bluetooth	true, 4.1
Network	built-in wi-fi, ethernet
Headphones Output	no
Digital Optical Audio Outputs	1
Analog Audio Outputs	1
Component Video Inputs	1
Composite Video Inputs	0
DVI	0
VGA Ports	0
Smart Applications	amazon alexa, google assistant
Remote Control	standard
3D	no
Depth with Stand	13 inches
Height with Stand	38.5 inches
Width with Stand	61.8 inches
Net Weight with Stand	58 pounds
Depth without Stand	2.9 inches
Height without Stand	35.7 inches
Net Weight without Stand	56.9 pounds
