Vizio M220MV User Manual

VIZIO M190MV/M220MV User Manual
Version 1/26/2010 9
www.VIZIO.com
Wall Mounting Your HDTV
Your HDTV can be mounted on the wall for viewing. If you choose to mount your HDTV on the
wall, follow the instructions below.
1. Write down the serial number located on the back of your HDTV in the space provided on
page 1 to have it handy if you need to call for support.
2. Remove the stand base and neck:
a. Disconnect the cables from your HDTV.
b. Place your HDTV face down on a soft, flat surface
to prevent damage to the screen.
c. Flip the base 90 degrees.In this manner, the stand
neck will be out of view after the base is removed.
d. Loosen the wing screw and remove the stand
base.
3. Mount your HDTV on the wall:
a. Attach your HDTV to a wall mount (sold
separately) using the mounting holes in the back
panel of your HDTV (see illustration at the right).
b. Read the instructions that came with your specific
wall mount to properly hang your HDTV.
Wall Mounting Specifications
Screw Size
! M4 x 10
Screw Length
! 10.0 mm
Screw Pitch
! 0.7 mm
Hole Pattern
! VESA standard
100 x 100 mm
spacing

Vizio M220MV Specifications

General

Display diagonal	22 \
Native aspect ratio	16:9
Native refresh rate	60 Hz
Supported video modes	1080i, 1080p, 480i, 480p, 720p
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	20000:1
Viewing angle, horizontal	170 °
Supported graphics resolutions	1920 x 1080 (HD 1080)
3D	No
Built-in speaker(s)	-
Product color	Black
HDCP	Yes
USB 2.0 ports quantity	1
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	185 mm
Height (with stand)	373 mm
Weight (with stand)	3500 g
Depth (without stand)	44.5 mm
Width (without stand)	533 mm
Height (without stand)	350 mm
Weight (without stand)	3450 g
