CONNECTING A DEVICE - AUDIO & VIDEO CABLE TYPES
AV CABLE
AV cables (or Composite cables) are the
traditional way of connecting your devices
to your TV. Video signals are sent over the
yellow connector while audio is sent over
the red and white connectors.
• Video Resolutions up to 480i
• Analog Connection
• Audio and Video Signals
GOOD
COMPONENT VIDEO
Y L R
COAXIAL CABLE
Coaxial cables are the traditional way of
connecting antennas and cable television
signals to your TV. Coaxial cables carry both
audio and video signals through a single
connector.
• HD Video Resolutions up to 1080i
• Analog Connection
• Audio and Video Signals
BETTER
COAXIAL CABLE
Coaxial
COMPONENT CABLE
Component cables are designed to carry high
definition video signals along with additional
audio connections. Colors are delivered with
color information split up three different ways
over three connectors for video (separated into
Red, Blue and Green signals) and the left and
right audio connectors (Red and White).
• HD Video Resolutions up to 1080i
• Analog Connection
• Audio and Video Signals
HDMI CABLE
HDMI is the intelligent, all-digital interface
that delivers both dazzling quality and
unmatched ease of use. HDMI technology
transmits crystal-clear digital video along with
multi-channel surround audio. HDMI-connected
devices have the ability to automatically adjust
themselves for optimal viewing.
• HD Video Resolutions up to UHD*
• HD Audio
• Digital Connection
• Audio and Video Signals
BETTER
COMPONENT VIDEO
R L Pr/Cr Pb/Cb Y
HDMI
HDMI
BEST
* High-Speed HDMI cable required for UHD resolutions
15

Vizio P602ui-B3 Specifications

General

Screen Type	led
Wall Mount	400mm x 400mm
Screen Size	60 inches
Refresh Rate	240hz
USB Ports	1
Component Video Inputs	1
Composite Video Inputs	1
DVI	0
Remote Control	smart
3D	no
Width with Stand	53.59 inches
Depth without Stand	2.5 inches
Height without Stand	30.9 inches
Net Weight without Stand	48.7 pounds
