Vizio P602ui-B3 User Manual

4
To turn color channels off and on:
1. From the PICTURE MODE MANAGEMENT menu, use the Arrow
buttons to highlight Color Tuner, and then press OK. Th e
Color Tuner menu is displayed.
2. Use the Arrow buttons on the remote to highlight Red,
Green, or Blue.
3. Press the OK button to turn the color channel off or on. An X
appears over a color channel that has been turned off.
4. Use the Arrow buttons to highlight another color channel to
turn off or on. Only two color channels can be turned off at
the same time.
5. When you are finished with the color channels, press the
EXIT button.
Color Tuner
Red Green Blue Cyan Magenta Yellow
Hue 0 0 0 0 25 -14
Saturation -1 5 -4 0 -2 0
Brightness -24 0 -22 0 0 0
Offset 0 0 0
Gain 0 0 0
To adjust the 11 Point White Balance settings:
1. From the Color Tuner menu, use the Arrow buttons to
highlight Color Tuner, and then press the Left/Right Arrow
buttons until the 11 Point White Balance menu is displayed.
2. Use the Arrow buttons on the remote to highlight the Gain
and Color values you wish to adjust. Press the OK button
and use the Left/Right Arrow buttons to adjust the value
When you are finished press the OK button to save the
setting.
3. When you are finished, press the EXIT button.
11 Point White Balance
Gain Red Green Blue
5% 0 0 0
Adjusting the Color Tuner Settings
The Color Tuner settings allow you to adjust the HSB color and
11 point white balance, turn color channels off for testing, and
display color bar, flat, and ramp test patterns.
To adjust the HSB color settings:
1. From the PICTURE MODE MANAGEMENT menu, use the Arrow
buttons to highlight Color Tuner, and then press OK. Th e
Color Tuner menu is displayed.
2. Use the Arrow buttons on the remote to highlight the Hue,
Saturation, Brightness, Offset, or Gain of the color you wish
to adjust. Press the OK button.
3. Use the Left/Right Arrow buttons to adjust the value. When
you are finished press the OK button to save the setting.
4. When you are finished adjusting the color tuner settings,
press the EXIT button.
Color Tuner
Red Green Blue Cyan Magenta Yellow
Hue 0 0 0 0 25 -14
Saturation -1 5 -4 0 -2 0
Brightness -24 0 -22 0 0 0
Offset 0 0 0
Gain 0 0 0
27

Vizio P602ui-B3 Specifications

General

Screen Type	led
Wall Mount	400mm x 400mm
Screen Size	60 inches
Refresh Rate	240hz
USB Ports	1
Component Video Inputs	1
Composite Video Inputs	1
DVI	0
Remote Control	smart
3D	no
Width with Stand	53.59 inches
Depth without Stand	2.5 inches
Height without Stand	30.9 inches
Net Weight without Stand	48.7 pounds
