Vizio V21x-J8 User Manual

ENG - 23
Connecting with HDMI ARC
*
The following steps are for use with a VIZIO TV, steps may dier by TV manufacturer. See your TV’s user manual for more information.
†
CEC Function naming may dier by TV manufacturer. See your TV’s user manual for more information.
To connect using HDMI
*
:
What is HDMI Audio Return Channel (ARC)?
If you want to use the TV remote to control the sound bar volume:
Enable System Audio Control from the CEC menu.
• Using HDMI ARC, your TV can send audio to the sound bar using an HDMI cable.
• Connect your sound bar to your TV’s HDMI ARC port using an HDMI cable that is ARC compatible.
1. Connect one end of the HDMI cable to the HDMI 1 (ARC) port on the back of your TV.
2. Connect the other end to the HDMI (ARC) port on your sound bar.
3. From the AUDIO menu on your TV, change the Digital Audio Setting to Dolby Digital or Bitstream.
4. From the SYSTEM menu, enable CEC and ARC (SAC)
†
functions.
5. From the CEC menu, select Device Discovery to register the sound bar with the TV.

Vizio V21x-J8 Specifications

General

Game mode	Yes
Audio decoders	DTS TruVolume, DTS Virtual:X
RMS rated power	- W
Audio output channels	2.1 channels
Audio sample rate (24bit)	20 kHz
Wi-Fi	-
Bluetooth version	4.1
Connectivity technology	Wireless
Package depth	346 mm
Package width	993.9 mm
Package height	249.9 mm
Product color	Black

Weight and Dimensions

Depth	81.3 mm
Width	914.4 mm
Height	57.9 mm
Subwoofer width	195.1 mm
Subwoofer height	215.4 mm
Subwoofer weight	2700 g
