Values are based on a typical motor efficiency (eff2/eff3 border line). Motors with lower efficiency will also add to the power loss in the
adjustable frequency drive and vice-versa.
If the switching frequency is increased compared to the default setting, the power losses may rise significantly.
LCP and typical control card power consumption values are included. Further options and customer load may add up to 30 W to the
losses. (Though typical, only 4 W extra for a fully loaded control card, or options for slot A or slot B, each).
Although measurements are made with state of the art equipment, some measurement inaccuracy must be allowed for (
±
5%).
5) The three values for the max. cable cross-section are for single core, flexible wire and flexible wire with sleeve, respectively.
PK75 P1K1 P1K5 P2K2 P3K0 P4K0 P5K5 P7K5
Typical Shaft Output (hp [kW]) 1 [0.75] 1.5 [1.1] 2 [1.5] 3 [2.2] 4 [3] 5 [4] 7.5 [5.5] 10 [7.5]
Enclosure IP20, IP21 A3 A3 A3 A3 A3 A3 A3 A3
Enclosure IP55 A5 A5 A5 A5 A5 A5 A5 A5
Output current
Continuous (3x525–550 V) [A] 1.8 2.6 2.9 4.1 5.2 6.4 9.5 11.5
Intermittent (3x525–550 V) [A] 2.9 4.2 4.6 6.6 8.3 10.2 15.2 18.4
Continuous (3x551–600 V) [A] 1.7 2.4 2.7 3.9 4.9 6.1 9.0 11.0
Intermittent (3x551–600 V) [A] 2.7 3.8 4.3 6.2 7.8 9.8 14.4 17.6
Continuous kVA (525 V AC) [kVA] 1.7 2.5 2.8 3.9 5.0 6.1 9.0 11.0
Continuous kVA (575 V AC) [kVA] 1.7 2.4 2.7 3.9 4.9 6.1 9.0 11.0
Max. input current
Continuous (3x525–600 V) [A] 1.7 2.4 2.7 4.1 5.2 5.8 8.6 10.4
Intermittent (3x525–600 V) [A] 2.7 3.8 4.3 6.6 8.3 9.3 13.8 16.6
Additional specifications
IP20, IP21 max. cable-cross section
5)
(line
power, motor, brake and load sharing) [mm
2
(AWG)]
2)
4,4,4 (12,12,12)
(min. 0.2 (24))
IP55, IP66 max. cable cross-section
5)
(line
power, motor, brake and load sharing) [mm
2
(AWG)]
4,4,4 (12,12,12)
Max. cable cross-section
5)
with disconnect
6,4,4 (10,12,12)
Estimated power loss
at rated max. load [W]
4)
35 50 65 92 122 145 195 261
Weight, Enclosure IP20 (lb [kg]) 14.33
[6.5]
14.33
[6.5]
14.33 [6.5]
14.33
[6.5]
14.33
[6.5]
14.33
[6.5]
14.55
[6.6]
14.55 [6.6]
Weight, enclosure IP55 (lb [kg]) 29.76
[13.5]
29.76
[13.5]
29.76
[13.5]
29.76
[13.5]
29.76
[13.5]
29.76
[13.5]
31.31
[14.2]
31.31
[14.2]
Efficiency
4)
0.97 0.97 0.97 0.97 0.97 0.97 0.97 0.97
Table 10.7 Line Power Supply 3x525–600 V AC (FC 302 only)
