P30K P37K P45K P55K P75K
High/Normal Load
1)
HO NO HO NO HO NO HO NO HO NO
Typical Shaft output hp [kW] 40 [30] 50 [37] 50 [37] 60 [45] 60 [45] 75 [55] 75 [55] 100 [75] 100 [75] 125 [90]
Enclosure IP20 B4 C3 C3 C4 C4
Enclosure IP21 C1 C1 C1 C2 C2
Enclosure IP55, IP66 C1 C1 C1 C2 C2
Output current
Continuous (3x380–440 V) [A] 61 73 73 90 90 106 106 147 147 177
Intermittent (60 s overload)
(3x380–440 V) [A]
91.5 80.3 110 99 135 117 159 162 221 195
Continuous (3x441–500 V) [A] 52 65 65 80 80 105 105 130 130 160
Intermittent (60 s overload)
(3x441–500 V) [A]
78 71.5 97.5 88 120 116 158 143 195 176
Continuous kVA (400 V AC) [kVA] 42.3 50.6 50.6 62.4 62.4 73.4 73.4 102 102 123
Continuous kVA (460 V AC) [kVA] 51.8 63.7 83.7 104 128
Max. input current
Continuous (3x380–440 V) [A] 55 66 66 82 82 96 96 133 133 161
Intermittent (60 s overload)
(3x380–440 V) [A]
82.5 72.6 99 90.2 123 106 144 146 200 177
Continuous (3x441–500 V) [A] 47 59 59 73 73 95 95 118 118 145
Intermittent (60 s overload)
(3x441–500 V) [A]
70.5 64.9 88.5 80.3 110 105 143 130 177 160
Additional specifications
IP20 max. cable cross-section
5)
(line
power and motor)
35 (2) 50 (1) 50 (1) 150 (300 MCM) 150 (300 MCM)
IP20 max. cable cross-section
5)
(brake and load sharing)
35 (2) 50 (1) 50 (1) 95 (4/0) 95 (4/0)
IP21, IP55, IP66 max. cable cross-
section
5)
(line power, motor) [mm
2
(AWG)]
2)
50 (1) 50 (1) 50 (1) 150 (300 MCM) 300MCM (150)
IP21, IP55, IP66 max. cable cross-
section
5)
(brake, load sharing)
[mm
2
(AWG)]
2)
50 (1) 50 (1) 50 (1) 95 (3/0) 95 (3/0)
Max. cable size with line power
disconnect [AWG (mm
2
)]
2)
50, 35, 35
(1, 2, 2)
95, 70, 70
(3/0, 2/0, 2/0)
185, 150, 120
(350 MCM, 300
MCM, 4/0)
Estimated power loss
at rated max. load [W]
4)
570 698 697 843 891 1083 1022 1384 1232 1474
Weight,
enclosure IP21, IP55, IP66 (lbs [kg])
99.21 [45] 99.21 [45] 99.21 [45] 143.3 [65] 143.3 [65]
Efficiency
4)
0.98 0.98 0.98 0.98 0.99
Table 10.6 Line Power Supply 3x380–500 V AC (FC 302), 3x380–480 V AC (FC 301)
For fuse ratings, see 10.3.1 Fuses
1) High overload = 160% torque during 60 s. Normal overload = 110% torque during 60 s.
2) American Wire Gauge.
3) Measured using 16.5 ft. [5 m] shielded motor cables at rated load and rated frequency.
4) The typical power loss is at nominal load conditions and expected to be within
±
15% (tolerance relates to variances in voltage and
cable conditions).
