VLT FC 300 - Page 87

P11K P15K P18K P22K
High/Normal Load
1)
HO NO HO NO HO NO HO NO
Typical Shaft output at 550 V (hp [kW]) 10 [7.5] 15 [11] 15 [11] 20 [15] 20 [15] 25 [18.5] 25 [18.5] 30 [22]
Typical Shaft output at 575 V [hp] 11 15 15 20 20 25 25 30
Typical Shaft output at 690 V (hp [kW]) 15 [11] 20 [15] 20 [15] 25 [18.5] 25 [18.5] 30 [22] 30 [22] 40 [30]
Enclosure IP21, IP55 B2 B2 B2 B2
Output current
Continuous (3x525–550 V) [A] 14 19 19 23 23 28 28 36
Intermittent (60 s overload) (3x525–550
V) [A]
22.4 20.9 30.4 25.3 36.8 30.8 44.8 39.6
Continuous (3x551–690 V) [A] 13 18 18 22 22 27 27 34
Intermittent (60 s overload) (3x551–690
V) [A]
20.8 19.8 28.8 24.2 35.2 29.7 43.2 37.4
Continuous KVA (at 550 V) [KVA] 13.3 18.1 18.1 21.9 21.9 26.7 26.7 34.3
Continuous KVA (at 575 V) [KVA] 12.9 17.9 17.9 21.9 21.9 26.9 26.9 33.9
Continuous KVA (at 690 V) [KVA] 15.5 21.5 21.5 26.3 26.3 32.3 32.3 40.6
Max. input current
Continuous (3x525–690 V) [A] 15 19.5 19.5 24 24 29 29 36
Intermittent (60 s overload) (3x525–690
V) [A]
23.2 21.5 31.2 26.4 38.4 31.9 46.4 39.6
Additional specifications
Max. cable cross-section (line power,
load share and brake) [AWG (mm
2
)]
35,-,- (2,-,-)
Max. cable cross-section (motor) [AWG
(mm
2
)]
35, 25, 25 (2, 4, 4)
Max. cable size with line power
disconnect [AWG (mm
2
)]
2)
16,10,10 (6,8, 8)
Estimated power loss at rated max.
load [W]
4)
228 285 335 375
Weight, enclosure IP21, IP55 (lbs [kg]) 59.53 [27]
Efficiency
4)
0.98 0.98 0.98 0.98
Table 10.11 B2 Frame,
Line Power Supply 3x525–690 V AC IP21/IP55 - NEMA 1/NEMA 12 (FC 302 only)
