P30K P37K P45K P55K P75K
High/Normal Load* HO NO HO NO HO NO HO NO HO NO
Typical Shaft output at 550 V (hp
[kW])
30 [22] 40 [30] 40 [30] 50 [37] 50 [37] 60 [45] 60 [45] 75 [55] 75 [55] 100 [75]
Typical Shaft output at 575 V
[hp]
30 40 40 50 50 60 60 75 75 100
Typical Shaft output at 690 V (hp
[kW])
40 [30] 50 [37] 50 [37] 60 [45] 60 [45] 75 [55] 75 [55] 100 [75] 100 [75] 125 [90]
Enclosure IP21, IP55 C2 C2 C2 C2 C2
Output current
Continuous (3x525–550 V) [A] 36 43 43 54 54 65 65 87 87 105
Intermittent (60 s overload)
(3x525–550 V) [A]
54 47.3 64.5 59.4 81 71.5 97.5 95.7 130.5 115.5
Continuous (3x551–690 V) [A] 34 41 41 52 52 62 62 83 83 100
Intermittent (60 s overload)
(3x551–690 V) [A]
51 45.1 61.5 57.2 78 68.2 93 91.3 124.5 110
Continuous KVA (at 550 V) [KVA] 34.3 41.0 41.0 51.4 51.4 61.9 61.9 82.9 82.9 100.0
Continuous KVA (at 575 V) [KVA] 33.9 40.8 40.8 51.8 51.8 61.7 61.7 82.7 82.7 99.6
Continuous KVA (at 690 V) [KVA] 40.6 49.0 49.0 62.1 62.1 74.1 74.1 99.2 99.2 119.5
Max. input current
Continuous (at 550 V) [A] 36 49 49 59 59 71 71 87 87 99
Continuous (at 575 V) [A] 54 53.9 72 64.9 87 78.1 105 95.7 129 108.9
Additional specifications
Max. cable cross-section (line
power and motor) [AWG (mm
2
)]
150 (300 MCM)
Max. cable cross-section (load
share and brake) [mm
2
(AWG)]
95 (3/0)
Max. cable size with line power
disconnect [AWG (mm
2
)]
2)
95, 70, 70
(3/0, 2/0, 2/0)
185, 150, 120
(350 MCM, 300
MCM, 4/0)
-
Estimated power loss
at rated max. load [W]
4)
480 592 720 880 1200
Weight, enclosure IP21, IP55 (lbs
[kg])
143.3 [65]
Efficiency
4)
0.98 0.98 0.98 0.98 0.98
Table 10.12 C2 Frame,
Line Power Supply 3x525–690 V AC IP21/IP55 - NEMA 1/NEMA 12 (FC 302 only)
Specifications
VLT
®
AutomationDrive Instruction
Manual
10-12 MG33AM22 - VLT
®
