VLT FC 300 - Page 96

Enclosure
size
Power (hp [kW]) Recommended
fuse size
Recommended
Max. fuse
Recommended circuit
breaker
Moeller
Max trip level [A]
A1 0.34–2 [0.25–1.5] gG-10 gG-25 PKZM0-16 16
A2 0.34–3 [0.25–2.2] gG-10 (0.25–1.5)
gG-16 (2.2)
gG-25 PKZM0-25 25
A3 4–5 [3.0–3.7] gG-16 (3)
gG-20 (3.7)
gG-32 PKZM0-25 25
B3 7.5 [5.5] gG-25 gG-63 PKZM4-50 50
B4 10–20 [7.5–15] gG-32 (7.5)
gG-50 (11)
gG-63 (15)
gG-125 NZMB1-A100 100
C3 25–30 [18.5–22] gG-80 (18.5)
aR-125 (22)
gG-150 (18.5)
aR-160 (22)
NZMB2-A200 150
C4 40–50 [30–37] aR-160 (30)
aR-200 (37)
aR-200 (30)
aR-250 (37)
NZMB2-A250 250
A4 0.34–3 [0.25–2.2] gG-10 (0.34-2) [0.25-1.5]
gG-16 (3) [2.2]
gG-32 PKZM0-25 25
A5 0.34–5 [0.25–3.7] gG-10 (0.34-2) [0.25-1.5]
gG-16 (3-4) [2.2-3]
gG-20 (5) [3.7]
gG-32 PKZM0-25 25
B1 7.5–10 [5.5–7.5] gG-25 (7.5) [5.5]
gG-32 (10) [7.5]
gG-80 PKZM4-63 63
B2 15 [11] gG-50 gG-100 NZMB1-A100 100
C1 20–30 [15–22] gG-63 (20) [15]
gG-80 (25) [18.5]
gG-100 (30) [22]
gG-160 (20-25) [15-18.5]
aR-160 (30) [22]
NZMB2-A200 160
C2 40–50 [30–37] aR-160 (40) [30]
aR-200 (50) [37]
aR-200 (40) [30]
aR-250 (50) [37]
NZMB2-A250 250
Table 10.14 200–240 V, Frame Sizes A, B and C
Specifications
VLT
®
AutomationDrive Instruction
Manual
10-20 MG33AM22 - VLT
®
