VLT FC 300 - Page 97

Enclosure
size
Power [kW] Recommended
fuse size
Recommended
Max. fuse
Recommended circuit
breaker Moeller
Max trip level [A]
A1 0.37–1.5 gG-10 gG-25 PKZM0-16 16
A2 0.37–4.0 gG-10 (0.37–3)
gG-16 (4)
gG-25 PKZM0-25 25
A3 5.5–7.5 gG-16 gG-32 PKZM0-25 25
B3 11–15 gG-40 gG-63 PKZM4-50 50
B4 18.5–30 gG-50 (18.5)
gG-63 (22)
gG-80 (30)
gG-125 NZMB1-A100 100
C3 37–45 gG-100 (37)
gG-160 (45)
gG-150 (37)
gG-160 (45)
NZMB2-A200 150
C4 55–75 aR-200 (55)
aR-250 (75)
aR-250 NZMB2-A250 250
A4 0.37–4 gG-10 (0.37–3)
gG-16 (4)
gG-32 PKZM0-25 25
A5 0.37–7.5 gG-10 (0.37–3)
gG-16 (4–7.5)
gG-32 PKZM0-25 25
B1 11–15 gG-40 gG-80 PKZM4-63 63
B2 18.5–22 gG-50 (18.5)
gG-63 (22)
gG-100 NZMB1-A100 100
C1 30–45 gG-80 (30)
gG-100 (37)
gG-160 (45)
gG-160 NZMB2-A200 160
C2 55–75 aR-200 (55)
aR-250 (75)
aR-250 NZMB2-A250 250
Table 10.15 380–500 V, Frame Sizes A, B and C
