Steering switch set
29
1.Rear brake lever
2.TCS switch
3.Dimmer switch/Overtaking switch
4.Emergency switch
5.engine stop
6.Front brake lever
7.Starting switch
8.Horn switch
9.Left lever
10.Turning signal light switch
21
High/Low beam and overtaking switch
When the high beam/overtaking switch push forward to" ",the high beam gets on,while the indicating light on
instrument " " also gets on.
When the high beam/overtaking switch move back to" ",the low beam light gets on,while the indicating light on
instrument" "gets off.
When move back the switch" PASSING ",the high beam is on,while the indicating light on instrument is on" ",and it
recovers when released the switch.
!
Warning
The headlight could be on when the engine is stopped, the light depends on battery, so please don’t long time turn
on the light when the engine is stopped.
10
8
6
1
5
7
23
4
9
