Adjustment for throttle grip
After the clearance of throttle cable adjusted, make sure the throttle lever could return automatically whose
idling speed should not rise.
After the clearance of throttle cable adjusted, turn the handle bar to the left and right limit, whose idling speed
should not rise.
!
Caution
36
1
2
3
·The throttle lever is for controlling engine rotation
·Turn to your own direction is acceleration, the
opposite direction is deceleration.
·The adjustment for clearance of throttle cable
–Remove the rubber jacket 1.
–Loosen the locking nut 2.
–Turn the adjustor 3 to let the clearance of throttle
cable to suitable distance.
–Lock up the nut 2
–Re-assemble the rubber jacket 1
