Routine check table for key fastening parts
62
Ref. No. Fastening position Installation position Thread Numbers Torque (N.m)
Front disc brake pump
Rear disc brake pump
2 Locking nut and bolt for handle bar Handle bar and steering stem M10 x 1.25 1
40±5
3 Dust proof nut for steering stem Steering stem and frame M26 x 1 1
Fasten by torque of 80N.m for front wheel, then
swing left and right twice, then turn back by 1/2
round, then lock up by torque of 10N.
4 Locking nut for steering stem Steering stem and frame M26 x 1 1 65±5
5 Locking bolt for front shock absorber Front shock absorber and steering stem M10 x 1.25 4 40±5
6 Locking nut and bolt for front wheel Front wheel and front shock absorber M12 x 1.25 1 50±5
Front brake plate and front wheel 5
Rear brake plate and rear wheel 4
Ring gear and front wheel 3
Ring gear and rear wheel 4
9 Locking bolt for fuel tank Fuel tank and frame M8 x 1.25 4 22±3.3
10 Locking bolt and nut for side stand Side stand and frame M10 x 1.25 1 40±5
Engine holder and frame 1
Engine holder and engine 1
Left rear shock absorber and frame 1
Left rear shock absorber and frame 1
Left rear shock absorber and engine 1
Right rear shock absorber and its connecting piece 1
Bracket of left main footrest and frame 2
Bracket of right main footrest and frame 2
Left pillion step set and frame 2
Right pillion step set and frame 2
16 Locking bolt and nut for windshield’s bracket Windshield’s bracket and frame M8 x 1.25 2 26±4
17 Cap-shaped nut for locking muffler Muffler and engine M8 x 1.25 2 26±4
18 Locking bolt for muffler Muffler and connecting piece of rear shock absorber M8 x 1.25 3 26±4
19
Locking bolt for connecting piece of rear shock
absorber
Connecting piece of rear shock absorber and engine M10 x 1.25 2 40±5
20 Locking nut for output shaft of rear wheel Output shaft of rear wheel M16 x 1.25 1 120±5
21 Locking bolt for luggage rack Luggage rack and frame M8 x 1.25 4 22±3.3
22 Locking bolt for air filter Air filter and engine M6 2 9±1.35
Front upper brake pump and handle bar
Rear upper brake pump and handle bar
24 Locking bolt for ABS oil tube ABS oil tube and ABS controller M10 x 1.0 4 24±3
ABS oil tube and front brake pump
ABS oil tube and rear brake pump
Oil tube of high pressure and fast change joint
Oil tube of high pressure and fuel filter
26 Connecting piece for high pressure oil tube Clamp set 4 4.5±0.5
23 Locking bolt for upper brake pump M6 4 9±1.35
25 Locking bolt for ABS oil tube M10 x 1.25 4 35±5.25
14 Locking bolt for main footrest’s bracket M6 9±1.35
15 Locking bolt for pillion step M8 x 1.25 22±3.3
12 Locking nut for rear shock absorber M12 x 1.25 50±5
13 Locking bolt for rear shock absorber M8 x 1.25 26±4
8 Locking bolt for ring gear M5 4.5±0.9
11 Shaft and nut for engine holder M10 x 1.25 50±5
1 Installation bolt for lower disc brake pump M8 x 1.25 4
26±4
7 Locking bolt for disc brake plate M8 x 1.25 26±4
