Vogelsang VX215QD - Fig. 29: Cartridge Mechanical Seal on the Gearbox

Repair
WBV.PU.002.EN VX215QD V2.0
65
a)
b)
c)
Fig. 29: Cartridge mechanical seal on the gearbox
1
Set screw
4
O-ring (bearing seal housing)
2
Cylinder head bolt*
5
O-ring (seal carrier)
3
Hexagon head bolt*
A
Installation tool*
* included in tool with part no. PBA0082
