Bias Q5 User Guide V1.0
Page 6
Bias Q5
Bias Q5
Bias Q5
Bias Q5
Bias Q5
Bias Q5
Bias Q5
Bias Q5
Bias Q5
1 1
1 RU
1 RU
1 RU
Mounting brackets
1 1
2 2
2 2
3 3
3 3
4 4
4 4
5
1 2 3 4 5 6 7 8
Color code (TIA/EIA-568-B) Pin
ORANGE / WHITE 1
ORANGE 2
GREEN / WHITE 3
BLUE 4
BLUE / WHITE 5
GREEN 6
BROWN / WHITE 7
BROWN 8
Input
XLR-M pinout
Pin 1 GND
Pin 2
HOT
Pin 3
COLD
HOT
1
2
3
COLD
GND
RJ45
D
E
F G
