Voith CTO-B45202 - Technical Data Specifications

Instruction and Operating Manual
Overspeed Protector CTO-B45202
2019 / 02
J.M. Voith SE & Co. KG │ Division Digital Ventures
Page: 4 / 25
918 3626018864 en
D – 74564 Crailsheim
Version: 2.1
1 Technical Data
Overspeed protector type CTO-B45202
Article number
91868550
Instruction Manual No. 918 3626018864
Product identification
See nameplate
EC Declaration of Conformity
See separate document
EC marking
Protection IP 65 as per EN 60529
Explosion protection
II 2G IIC T4
Ambient temperature T
A
(operation)
-30 ... +60
°C
Ambient temperature (storage) -40 ... +90
Installation conditions
Indoor installation
Outdoor installation
Offshore
Industr.
atmosph.
Hydraulic Data
Supply pressure Pmax 25 bar
Operating medium
Type Hydraulic oil as per DIN 51524
Turbine oil as per DIN 51515
High-flash point fluid
1)
Oil temperature during operation
+10 … +60
°C
Cleanliness grade (ISO VG 4406)
- / 16 / 13
Viscosity (DIN 51519) ISO VG 32 … ISO VG 46
Leakage (T
oil
= 50 °C and P=10 bar)
< 2
l/min
Mechanical Data
Installation positions
Dimensions, fastening
See Chapter 9
Hydraulic connection
See Chapter 9
Sealing material
FPM
2)
Special design
4)
NBR
3)
Weight
approx. 14
kg
1) According to customer's request or especially for high-flash point fluids
2) Fluor-caoutchouc
3) Acrylnitril-Butadien-caoutchouc
4) according to the customer's specification and consultation with J.M. Voith SE & Co. KG │ Division Digital Ventures
