Volcano VR Mini - Page 30

VOLCANO VR Mini
VOLCANO VR1
VOLCANO VR2
VOLCANO VR3
VOLCANO VR-D
Parameter Unit of measure
VOLCANO
VR Mini
VOLCANO
VR1
VOLCANO
VR2
VOLCANO
VR3
VOLCANO
VR-D
1XPEHURIURZVLQWKHKHDWHU 2123---
0D[LPXPDLUÀRZUDWH m³/h 2100 5300 4850 5700 6500
+HDWLQJSRZHUUDQJH kW 3-20 5-30 8-50 13-75 -
Maximum temperature of the heating agent °C 130 -
Maximum operating pressure* MPa 1.6 -
Maximum horizontal air stream range m 14 23 22 25 28
Maximum vertical air stream range m 812111215
Water capacity dm³ 1.12 1.25 2.16 3.1 -
Ferrule diameter " 3/4 -
Weight of the device kg 17.5 27.5 29 31 22
3RZHUVXSSO\YROWDJH V/Hz 1 ~ 230/50
0RWRUSRZHU kW 0.115 0.28 0.41
Motor current A 0.53 1.3 1.7
0RWRUSRZHU(& kW 0.095 0.25 0.37
Motor current EC A 0.51 1.3
1.7
Motor speed
rpm 1450 1380
Motor IP
54
Motor IP EC
44
NOTE Data concerning VOLCANO working parameters for a heating agent with a different temperature can be provided upon request
30
EN
