4. ASSEMBLY
NOTE Installation location should be suitably selected with special consideration of potential loads and vibrations.
Prior to any installation or maintenance works, disconnect the device from the power supply and secure it against accidental power-up.
8VH¿OWHUVLQWKHK\GUDXOLFV\VWHP%HIRUH\RXFRQQHFWWKHK\GUDXOLFOLQHVHVSHFLDOO\VXSSO\OLQHVWRWKHGHYLFH\RXVKRXOGFOHDQULQVHWKHLQVWDOODWLRQE\GUDLQLQJWZROLWUHVRXWRILW
NOTE,WLVQHFHVVDU\WRPDLQWDLQDPLQLPXPGLVWDQFHRIPIURPWKHZDOORUWKHFHLOLQJRWKHUZLVHWKHGHYLFHFDQPDOIXQFWLRQWKHIDQFDQEHGDPDJHGRULWVRSHUDWLQJQRLVHFDQLQFUHDVH
,IWKHGHYLFHZLOOEHLQVWDOOHGRQDZDOORUXQGHUDFHLOLQJREVHUYHWKHIROORZLQJIDFWRUV
mounting height
OPT. 2-5m (Volcano V mini) OPT. 2,5-8m (Volcano VR1, VR2, VR3)
OPT. 3-8m (Volcano V mini) OPT. 3-11m (Volcano VR1, VR2) OPT. 3-12m (Volcano VR3) OPT. 6-15m (Volcano VR-D)
* for vertical air guides adjustment
distance between units – recommended distance 6-12m (Volcano VR1, VR2, VR3), 3-7m (Volcano VR Mini), in order to ensure even hot air diffusion
range of air stream
Max. 14m* (Volcano V mini)
Max. 22m* (Volcano VR1, VR2)
Max. 25m* (Volcano VR3)
Max. 28m* (Volcano VR-D)
Max. 2m** (Volcano V mini)
Max. 13m* (Volcano VR1, VR2)
Max. 15m* (Volcano VR3, VR-D)
* for horizontal air guide adjustment
** for symmetric air guide adjustment at an angle of 45°
device noise level (depending on acoustic characteristics of a room)
RSHUDWLRQPRGHRIWKHKHDWLQJGHYLFHHJLWFDQDOVRRSHUDWHDVDQDLUPL[LQJGHYLFHSUHYHQWLQJDLUVWUDWL¿FDWLRQ
direction of air distribution should be controlled in a way that prevents draughts. Air stream must not be directed at walls, brackets, girders, cranes, shelves, machines, etc.
OPT. 3-7m
(Volcano VR Mini)
OPT. 6-12m
(Volcano VR1, VR2, VR3)
OPT. 2-5m (Volcano VR Mini)
OPT. 2,5-8m (Volcano VR1, VR2, VR3)
