– Set multimeter measuring range to 20 A, and using auxiliary
cables from -V.A.G 1594 A- , connect multimeter in series be‐
tween the contacts -1- of the connector and fuel pump.
Note
The Multimeter -V.A.G 1715 - test probe can also be inserted be‐
tween the contact -1- connector and the fuel pump by using the
adapter cables of the Multimeter -V.A.G 1715 - .
– Connect contacts -4- of connector and fuel pump by using the
adapter cables from -V.A.G 1594 A- .
– Start engine and run at idle speed.
– Measure current at fuel pump. Specification: 6,3...7.8 A.
– If the values measured lie outside the specifications:
– Replace fuel pump ⇒ page 91 .
1.9 Accelerator mechanism - repair
1 - Support
❑ Remove and install ⇒
Rep. Gr. 46 .
2 - Connector
❑ Black, 6-pin.
3 - Accelerator pedal position
sensor -G79-
❑ Not adjustable.
❑ Accelerator pedal posi‐
tion sensor transmits
the pedal position to en‐
gine command unit.
❑ Remove feet rest area
cover to remove sensor.
4 - 10 Nm
Fox 2004 ➤
3 - Cyl. diesel engine - Edition 02.2009
94 Rep. Gr.20 - Supply system - Fuel tank, fuel pump
