– Loosen the spring clamp -1- and remove the air duct hose
-2-.
– Unclip the vacuum line -1- from the air filter housing and loosen
the spring clamp -2-.
– Carefully remove the air filter housing from the turbocharger
intake tube.
– Remove the crankcase ventilation hose -1-.
– Remove the bolt -2- and gently lift the air filter housing.
Note
There are vacuum lines attached to the bottom of the air filter
housing.
– Disconnect the vacuum lines from the bottom of the air filter
housing.
– Remove the air filter housing upward.
– Remove the screws -1- on the bottom of the air filter.
– Remove the air filter bottom section and remove the air filter
element.
Installing
Golf 2013 ➤ , Golf Sportsvan 2015 ➤ , Golf Variant 2014 ➤ , e-Golf 2014 ...
Maintenance - Edition 06.2015
4. Procedure Descriptions 123
