48-10
Airbag Spiral Spring, removing and
installing
Remove airbag unit Page 48-7
Remove steering wheel Page 48-8
- Separate single connector for horn.
Install steering wheel Page 48-9
Install airbag unit Page 48-7
Note:
- Remove screws -1- and remove Airbag Spiral
Spring -2- from steering wheel.
When removing and installing the Airbag Spiral
Spring, ensure that it is in the center position.
As a new part the Airbag Spiral Spring is secured
in the center position by a cable tie.
Page
10
of
99
Steering
12/7/2004
