Display Operation
Turn on the display and bike by pressing the POWER button located on the side of the display.
Press the adjustment buttons "<" , ">" to choose the pedal assist (PAS) level.
There are5PAS levels to choose from:
The bike battery must be charged for the display to function
PAS 0: Fitness Mode - 0% Motor Assist
PAS 1: Aerobic Mode - 30% Motor Assist
PAS 2: Eco Mode1- 50% Motor Assist
PAS 3: Eco Mode2- 65% Motor Assist
PAS 4: Climbing Mode1- 80% Motor Assist
PAS 5: Climbing Mode2- 100% Motor Assist
O
DO : Total distance (km)
Press the function button "M" on the display to switch
between each function:
T
RIP Displays trip riding mileage (km)
E
00 : Device check: E00 =
no errors
Display
Throttle
Shifter
Throttle Operation
The throttle located on the left side of the handlebars allows you to accelerate
without pedaling regardless of the PAS level selected. For safety reasons, the throttle
will only function when the bike is going at a minimum speed of 6 km/h.
Assembly Steps
Step 2: Lift up the head tube and lock in place using the head tube
buckle.
Step 3: Open the seat post clamp, adjust the height of the saddle and lock
the clamp.
Step 1: Gently separate the magnetic frame buckle, unfold the frame and lock in place using
the frame buckle.
.
1: Open the box and then unfold the bike as per the following steps.
