Folding Steps
2: The folding method is shown below:
Step 1: Open the seat post clamp, put down the seat post and then lock the clamp.
Step 2: Open the folding buckle of the head tube and fold down.
Step 3: Open the frame fold clamp, fold the frame and connect magnet to metal plate.
3: Please useawrench to install the pedals
Pedal Assembly
Step 2: Connect the corresponding pedal to
the screw hole on the crank arm and tighten
the screw.
Step 3: Pedal assembly ¿QLVKHd as
displayed in the picture.
Step 1: The left and right pedals are LGHQWL¿HG,
"L" means left side, and "R"
means right side. Make sure to install the
pedals on the correct side.
Tip: Add some lubricating oil to the screw for easier
tightening.
