7. Backlight LC-display with indication of the output voltage (U), current (I), power (P)
settings and indication of the U-,I-, and P-Limits. Additionally, indication of OUTPUT „ON“
or „OFF“ and keypad locked or unlocked.
8. AC power socket
9. RS-232 Interface (with optocoupler) for connection to a PC
10. Cooling slots
Table of Content
Page
Illustration 3
Introduction 10
Intended use 10
Operating elements 10
Table of content 11
Safety instructions 11
Function description 13
Operating instructions
A.) Casic settings, general 13
B.) Setting the limits 13
C.) „Key input“ settings 14
D.) Output-adjustment 14
E.) PC-connection, „REM“-key 14
Disposal 14
Rectification of faults 14
Maintenance 15
Technical Datas and specifications 15
Safety instructions
Damage caused by failure to observe the operating instructions voids the guarantee! We
accept no liability for consequential damage resulting from this. We accept no
responsibility for damage to property or injury to persons caused by improper operation
or failure to observe the safety instructions. such cases void the guarantee.
Pay attention to the following symbols:
Caution! Dangerous Voltage!
Danger!
Useful tip/hint for operation
Installation and handling savety instructions
Please note the following rules when installing the instrument:
- Avoid the use in extremly cold or hot locations or next to a heeting van or a soldering machine.
- Never switch on the item immediately when it has been brougth from a cold into a warm room.
The condensation can destroy the item. Allow the item to come to room temperature before
switching it on.
- Never cover the cooling slots or the vents of the housing, because otherwise heat built –up
and destroy the item.
- Never place the item onto its front panel, because the operation-panel could brake.
