CAUTION!
After opening the housing or remove parts, only when this is not possible without
tools, voltage carring components can expose. Connection points may also be live.
Before any internal adjustment, maintenance, repair or change of components, the
DPS must be removed from all power sources and loads. An internal adjustment or
repair under „live“ condition, only must be performed by a specialist fimilar with the
relevant regulations. Capacitors inside the DPS can remain charged, even when the
unit has been disconnected from all power sources and loads.
Maintenance
Concerning the maintenance and changing of fuses, pay attention to the safety instruction.
Modification of the circuit voids the guarantee. For repairs or internal adjustments contact our
service department. For cleaning only use a clean, dry, antistatic and lint-free cleaning cloth.
CAUTION
Do not use any carbonaceous cleaning agents or petrol, alcohol or similar for
cleaning. The surface of the unit will be attaced from this. Additionally, the fumes are
explosive and bad for the health. Do not use any sharp-edged tools, screwdrivers,
metal brushes or similar for cleaning. Außerdem sind die Dämpfe
gesundheitsschädlich und exlosiv.
Technical Datas
General:
Operating voltage : 230VAC ±10%
Power frequency : 50Hz
Power consumption : max. approx. 300VA
Power output : max. approx. 200W
Output Voltage DPS 2010 : 0 bis 20VDC; Resolution 10mV-Steps
Output Voltage DPS 4005 : 0 bis 40VDC; Resolution 10mV- Steps
Output Voltage DPS 8003 : 0 bis 80VDC; Resolution 10mV- Steps
Output current DPS 2010 : 0 bis 10A; Resolution 10mA- Steps
Output current DPS 4005 : 0 bis 5A; Resolution 10mA- Steps
Output current DPS 8003 : 0 bis 2,5A; Resolution 10mA- Steps
Voltage stability (U) with 100% load swing : </= 10mV
Current stability (I) with 100% load swing : </= 5mA
Voltage stability with ±10% ACvoltage
change
: </= 0,05%
Current stability with ±10% ACvoltage change
: </= 0,05%
Ripple at nominal load : approx. 15mVrms
Display : multi-line LCD with backlight
Fuse F1 : Slow-blow 6,3A / 250V
Fuse F2 : Slow-blow 1A / 250V
Weight : approx. 3kg
dimensions (B x H x T) : approx. 275 x 135 x 300 mm
Environmental conditions
Operating temperature range : 0 bis + 40°C
Relative humidity : approx. 80%, non-condensing
Storage temperature range : -20°C bis +60°C
