Troubleshooting
In purchasing the DMM, you have acquired a product which has been designed to the state of the
art and is operationally reliable.
Nevertheless, problems or faults may occur.
For this reason, the following is a description of how you can eliminate possible malfunctions
yourself.
Please observe the safety instructions!
Error Possible cause Remedy
The multimeter Is the battery dead? Check the battery status. Battery
doesn’t function replacement
No measured value Is the wrong measurement function Check the display (AC/DC)
change. active (AC/DC)? measurement value change and switch
the function if necessary.
Did you use the wrong measuring Check the measuring socket setting.
sockets?
Is the fuse for the current ranges or Check the fuses.
the low Ohm range defect?
Is the Hold function activated Press the “HOLD” button to
(display "HOLD")
deactivate this function.
Repairs other than those described should only be carried out by an authorised spe-
cialist. If you have queries about handling the measuring device, our technical sup-
port is available under the following telephone number:
Voltcraft®, 92242 Hirschau, Lindenweg 15, Tel.-No. 0180 / 586 582 7.
Technical Data
Display LCD, 4000 Counts (digits) with bargraph
Measuring rate approx. 2 measuring operations/second
Measuring lead length approx. 80 cm each
Measuring impedance >10MΩ (V range)
Automatic Power-Off approx. 30 minutes
Voltage supply 6 x mignon batteries (AA)
Working conditions 0 - 40°C (<80%rF)
Operating altitude max. 2,000 m
Storage temperature -10°C to +60°C (<70%rF)
Earth DMM approx. 550 g
Dimensions (LxWxH) 200 x 92 x 50 (mm)
Over-voltage category CAT III 600 V, Impurity level 2
