Always measure in parallel
to the respective consumer
• Connect the measuring lines to the meter.
• Choose the symbol for voltage measurement “
” with the adjustment wheel “6”.
• Hold the button „AC/DC“ (8) down for about 2 seconds to switch from direct current (DC)
measurement to alternate current (AC) measurement. The matching function is symbolized
as „AC“ or „DC“ on the display. The function will switch when the button is pressed again for
about 2 s.
• Connect the two measuring prods with the object to be measured.
• The measured value is indicated on the LC display.
• Remove the measuring lines from the object to be measured after completion of the measu-
rement and switch off the measuring device. For this, turn the adjustment wheel “6” into the
position “OFF”.
