O. Specifications
Model
BC-1230P
BC-1240P
BC-1260P
Output
Charge Voltage Selections (all models)
Absorption V
Float V
Standby V
WET
14.5V
13.5V
Float Voltage less 4%
LiFePO4
14.6V
13.6V
N/a
LiFePO4 #2
14.4V
13.6V
N/a
AGM (Default setting)
14.4V
13.2V
Float Voltage less 4%
AGM #2
14.3V
13.4V
Float Voltage less 4%
GEL #2
14.2V
13.7V
Float Voltage less 4%
CALCIUM
15.1V
13.8V
Float Voltage less 4%
User Define 1
12V - 16V Adj
User Define 2
12V - 16V Adj
Lead Crystal
14.7V
13.6V
N/a
Equalization
15.5V
Maximum Output Charging Current (Continuous)
30A
40A
60A
Recommended Battery Capacity Range
(for all battery type)
12 – 300AH
15 – 400AH
20 - 600AH
Soft Start Bulk Charge
Battery Voltage to Trigger (cut-in) Soft Start
Bulk Charge Mode
<10.5V
Soft Start Bulk Charge Current (Current Limit)
1/2 of the charging current
1/2 of the charging
current
1/2 of the charging
current
Ripple and Noise (Peak to Peak)
<200mV
<200mV
<200mV
Efficiency at Maximum Power (230V)
>83%
>83%
>83%
Dual Bank Charging (Battery must be of same type)
Yes
Yes
Yes
Input
AC Voltage Range
200 – 240V 50Hz~
AC Current at Full Load (230V)
2.5A
3.5A
5.0A
Protection
Overload
90-110% Rated Output Current or 50% Rated Output Current (Soft Charge)
Protection Type : Constant Current Limiting, recovers Automatically after
Fault Condition is Removed.
Short Circuit
Recovers Automatically if Fault Condition is Removed within 20 seconds
Otherwise the charger will shut down until re-start the charger again
Reverse Polarity
Automotive type Blade Fuse
Over Temperature
Protection Type: Shut Down
OVP Output Over Voltage
Yes
Cooling
Cooling Method
Thermostatic, Variable Speed Fan
Indicators
4-Stage Battery Charger
Yes
Charge Phase Bulk / Absorption / Float
Yes
Fault Mode
Yes
Over Temp
Yes
Charger ON
Yes
Fuses
AC Fuses at IEC AC Power Socket
T3.15A
T4A slow blow
F8A
DC Car Blade Fuse
25Ax2
30Ax2
30Ax3
Accessories
Supplied Accessories
Remote Temperature sensor, ac cable, spare ac fuse at socket, spare dc
fuses, CD Software, USB Cable
Optional Accessory
Remote Control Panel (Model:HBR-3100)
Approvals
Safety :
CE: EN 60335
SAA: AS/NZS 60335.1, AS/NZS 60335.2.29
(Include clause 21.102: Vibration Test)
Yes
EMC: EN 55014; EMF: EN50366
Yes
Others
Dimensions and Weight
200x80x260mm ; 3.2kg
200x80x260mm ;
3.2kg
200x80x320mm ; 4.2kg
Remarks
All values are based on the standard ambient temperature 25°C and pressure 0.1Mpa.
