SG: 0.73V
Q8
Resistor
BC: 356k
BE: 413k
Short or explosion
Diode
BC: 0.59V
BE: 0.61V
U8
Diode
PIN5 T
O PIN7: 0.48V
PIN5 T
O PIN6: 0.6
4V
Short or other
values
R203
Resistor
0.5 ohm
Open or other
values
R204
Resistor
100 ohm
Open or other
values
D53
1
Diode
+ to -: 0.52V
- to +: OL
Short or explosion
R67
Resistor
10 ohm
Open or other
values
D3
Diode
+ to -: 0.4V
- to +: 0.7V
Short or explosion
D49/D57
Diode
+ to -: 0.45V
- to +: OL
Short or explosion
U7
Diode
PINI to PINO: 0.56V
PINO to PING: 0.44V
PINI to PING: 0.45V
Short or explosion
U10
Diode
PINA
TO PINI:
0
.45V
PINA
TO PINO:
0
.5V
Short or explosion
TX4
Resistor
PIN1 T
O PIN3: 0.4 ohm
Short or other
values
Note1:
When test the D53; please remove the R67 from the board, otherwise the test
result is not right
3.6 Check
A
C SPS on MPPT
boa
rd
The F7 are (FUSE 3A
125V)
The NTC4 are (NTC 10 OHM 3.0A)
The REC3 are (GBU4M 4A
1
000V UFST)
Th
e D83 are (RHRP8120 8A
1200V)
The Q20 are (IRFBG30 3.1A
1000V
)
The Q19 are (2SC5353BL
3A
750V)
27
29
