Volvo Penta TAMD73P - Page 35

33
F
TAMD63
SS S F S
SS S FS S
TAMD73, TAMD74 FV
FF
TAMD63, TAMD73, TAMD74
Note: Remove the cover on the seawater pump. Also remove the hose between the heat exchanger and the
reverse gear’s oil cooler, then drain off the water while draining the seawater system.
F = Freshwater cocks/plugs S = Seawater cocks/plugs V = Venting cocks
TAMD63 FV
FF
F
TAMD73, VV
TAMD74
