50
Oil Change – Reverse Gear
Connect a hose from the oil scavenger pump to the
dipstick tube on the reverse gear. Or the oil can also
be drained after removing the drain plug.
See also instructions under. “Oil Change – Engine”.
1. Fill with oil through the filler opening on the top of
the reverse gear. For Oil quality and capacity
refer to “Technical data” on pages 110–113.
Draining oil from the reverse gear
2. Start the engine and run it until the reverse gear
reaches operating temperature.
3. Check the oil level with the engine idling and with
the neutral position selected.
The oil level should reach the upper mark on the
dipstick. Top up if required.
Cleaning the reverse gear’s oil screen
MPM IRM 220, -280 MPM IRM 301, -302V
TD MG5061, MG5062V, TD MG507(A)-1
MG5075A, MG5085
TAMD63, TAMD73 and TAMD74
1. Lubricating oil filter
2. By-pass filter
3. Screw on the new filter by hand until the gasket
is in contact with the sealing surface. Then
tighten the filter a further 3/4 of a turn.
4. Fill with oil, start the engine and check for leaks.
Stop engine and check the oil level.
TAMD71
1. Lubricating oil filter
2. By-pass filter (accessory)
7740156 - Downloaded from www.volvopenta.com 22/07/2009 00:44:08
