09 Maintenance and service
Wiper blades
09
207
Wiper blades
G020330
NOTE
The wiper blades are different lengths. The
blade on the driver's side is longer than on
the other side.
Cleaning
For cleaning wiper blades and windscreen, see
page 190.
IMPORTANT
Check the wiper blades regularly.
Neglected maintenance shortens the serv-
ice life of the wiper blades.
Replacing the wiper blades, windscreen
G020329
1. Turn up the wiper arm.
2. Press the button located on the wiper
blade mounting and pull straight out (1),
parallel with the wiper arm.
3. Slide in (2) the new wiper blade until a
"click" is heard.
> Check (3) that the blade is firmly instal-
led and fold down the wiper arm.
