09 Maintenance and service
Fuses
09
``
217
Relay/fuse box in the engine compartment
G007446
The fuse box has 36 fuse positions. Be sure to
replace a blown fuse with a new fuse of the
same colour and amperage.
•
19 – 36 are of the "Mini Fuse" type.
•
7-18 are of the "JCASE" type, and for their
replacement we recommend that you visit
an authorised Volvo workshop.
•
1–6 are of the "Midi Fuse" type and must
only be replaced by a workshop. Volvo rec-
ommends an authorised Volvo workshop.
On the inside of the cover are tweezers to
assist removing and fitting fuses.
