09 Maintenance and service
Fuses
09
``
219
22. Subwoofer 25 A
23. Engine control module ECM
(5-cyl. petrol), Transmission
(TCM) (5-cyl auto) 10 A
Transmission (TCM) (4-cyl.
auto.) 15 A
24. Heated fuel filter, PTC ele-
ment oil trap (5-cyl. diesel) 20 A
25. Reserve –
26. Ignition switch 15 A
27. A/C compressor 10 A
28. Reserve –
29. Fog lamp, front 15 A
30. Engine control module ECM
(4-cyl. diesel) 3 A
31. Voltage regulator 4-cyl. 10 A
32. Injectors (petrol), mass air
flow sensor and turbo control
(5-cyl. diesel) 10 A
33. Lambda-sond, vacuum pump
(petrol), engine control mod-
ule (5-cyl. diesel), diesel filter
heater (4-cyl. diesel) 20 A
34. Pressure switch, climate con-
trol system (5 cyl.), ignition
coils (petrol), glow plugs and
EGR emission control (5 cyl.
diesel), fuel pump (4-cyl. die-
sel) 10 A
35. Engine sensors for valves,
relay coil, air conditioning
PTC element, oil trap (petrol),
engine control module ECM
(5-cyl. diesel), canister (pet-
rol), MAF mass air flow sensor
(5-cyl. petrol, 4-cyl. diesel),
turbo control and EGR emis-
sion control (4-cyl. diesel) 15 A
36. Engine control module ECM
(not 5-cyl. diesel), accelerator
pedal position sensor,
lambda-sond (5-cyl. diesel) 10 A
