Section 01: ENGINE
PA1578 SECTION 01 REVISED AUGUST 2012 6
1.2 ENGINE OVERVIEW
NOTE
For additional information concerning Volvo D13 engine components or engine-related components,
consult Volvo Trucks Canada or Volvo Trucks North America Web Site under: Parts & Service. On
Volvo web site, you will find detailed service procedures for parts replacement, repair and
maintenance.
FIGURE 2: D13F ENGINE, ALTERNATOR SIDE (TYPICAL)
1. Venturi Pipe 8. Fuel Pump
2. EGR Mixing Chamber 9. Hand Primer
3. Intake Manifold 10. Fuel/Water Separator
4. Engine Electronic Control Unit (EECU) 11. Fuel Filter
5. Breather Tube 12. Crankcase Ventilator
6. Air Compressor 13. Fan/Coolant Pump Belt
7. Power Steering Pump
