Volvo EC15E - Page 204

EC15E, mm (in) EC18E, mm (in) ECR18E, mm (in) EC20E, mm (in)
Dipper arm Short
arm
950
(37.4)
Long
arm
1150
(45.3)
Short
arm
950
(37.4)
Long
arm
1150
(45.3)
Short
arm
950
(37.4)
Long
arm
1150
(45.3)
Short
arm
1050
(41.3)
Long
arm
1350
(53.1)
K Dozer
blade,
maximum
reach at
ground level
(short blade /
long blade)
1028 (40.47) / —* 1082 (42.60) / 1272 (50.08) —* / 1288 (50.71)
L Overall
width
min./max
990 (38.98) /
—*
994 (39.13) / 1352 (53.23)
M Overall
length
3548
(139.69
)
3432
(135.12
)
3550
(139.76
)
3431
(135.08)
3309
(130.28
)
3707
(145.94
)
3554
(139.92
)
N Overall
height of
engine hood
1439 (56.65) 1433 (56.42) 1439 (56.65)
O
Minimum
ground
clearance
182 (7.17) 162 (6.38)
P Dozer blade
height (short
blade / long
blade)
221 (8.70) / —* 231 (9.09) / 231 (9.09) —* / 241 (9.49)
Q
Shoe width 230 (9.06)
R Ground
clearance to
superstructure
453 (17.83) 456 (17.95)
S Front slew
radius
1455
(57.28)
1476
(58.11)
1455
(57.28)
1476
(58.11)
1575
(62.01)
1568
(61.73)
1679
(66.10)
1732
(68.29)
T
Front slew
radius with
maximum
offset
1181
(46.50)
1184
(46.61)
1181
(46.50)
1198
(47.17)
1269
(49.96)
1287
(50.67)
1401
(55.16)
1450
(57.09)
U Overall
height
(canopy)
2298 (90.47) 2296 (90.39) 2298 (90.47)
V Overall
height (cab)
2334 (91.89) - 2334 (91.89)
202
Specifications
Dimensions
