Volvo EC15E - Page 205

EC15E, mm (in) EC18E, mm (in) ECR18E, mm (in) EC20E, mm (in)
Dipper arm Short
arm
950
(37.4)
Long
arm
1150
(45.3)
Short
arm
950
(37.4)
Long
arm
1150
(45.3)
Short
arm
950
(37.4)
Long
arm
1150
(45.3)
Short
arm
1050
(41.3)
Long
arm
1350
(53.1)
W Overall
width of
superstructure
1000 (39.37)
X Tail slew
radius
1018 (40.08) 688 (27.09) 1018 (40.08)
*not available
Specifications
Dimensions 203
