1 Bucket 10 Additional counterweight (optional)
2 Bucket cylinder 11 Undercarriage
3 Dipper arm 12 Travel motor
4 Dipper arm cylinder 13 Tracks
5 Boom 14 Superstructure
6 Boom cylinder 15 Boom offset cylinder
7 Working lights 16 Dozer blade
8 Rear hood 17 Dozer blade cylinder
9 Engine hood 18 Battery disconnect switch
Presentation
Machine view
